ML2 AV | Autonomous Vehicles



Compact Autonomous Robot with Configurable Payload Handling

The Bastian Solutions ML2 Mini Load AV is a flexible, compact and highly maneuverable option to automate a variety of applications; from manufacturing assembly lines to picking and sortation in distribution operations. The ML2 is engineered for maximum uptime and functionality, accommodating a variety of load handling appliance options allowing it to engage loads in a multitude of ways. Its robust controls, software connectivity, zero turn radius, and ability to navigate tight spaces, makes the ML2 a leading solution for medium to small load handling.

ML2’s versatility goes beyond its manufactured specifications. As the consultant, manufacturer and integrator, Bastian Solutions’ experts will tailor ML2 solutions to suit your operational requirements. With complete visibility to the vehicles and supporting material handling equipment, we can adjust any part of the automated system to better meet current and future goals. Comprehensive training and support, provides users the skills needed to control their own system.


Ready to find your solution?

How It Works

ml2-agv-automated-vehicle-with-conveyor-topper-400pxThe ML2 Mini Load AV is small in size but can accommodate a wide array of tasks and payload needs. It transports 200-kilogram loads to designated stops, pickups and drop off points at the full speed of 1.8 meters per second – no derating required. A key feature is the modular payload deck configuration, which can be fitted with numerous engineered to order standard and custom appliances.

In addition to being physically flexible, the ML2 is also adaptable. Equipped with natural features navigation, the ML2 uses LiDAR scanners to identify features in its environment and match them to a virtual map to determine its location and move along its programmed paths to designated pick up and drop off points. Turn signals, located at each of the four corners of the vehicle, denote which direction the vehicle will be traveling to increase safety.

Once the path has been planned, the vehicle’s unique independent drive suspension system maintains consistent traction as it traverses over various floor conditions. This unique suspension system not only protects the vehicle from damage but ensures the safety of the payload on top of the vehicle. In-process, in-floor charging allows the ML2’s battery to receive a charge while performing tasks, reducing downtime and footprint. Designed with true ZTR (zero turn radius), bidirectional travel and a Category 3 safety system with 360 field of view, the ML2 can safely operate in tight spaces and around existing infrastructure with ease.

Bastian Solutions’ integrated AVs (autonomous vehicles) utilize our proprietary middleware solution to seamlessly connect vehicles from various manufacturers to customers’ enterprise systems. With this pre-packaged software stack, users can orchestrate complex, multi-fleet AV systems, improving interoperability, productivity and adaptability to future operational needs.

Applications

Some of the many warehouse applications it can be employed in, include:

  • Small lot delivery to line side
  • Pick and place to P&D (pickup and delivery) stands
  • Picking and sortation
  • Assembly line conveyance
  • Custom applications

ml2-warehouse-autonomous-vehicle-400px

Benefits

  • Compact, highly maneuverable size to easily navigate tight spaces
  • Enables 24/7 automated operations
  • 360-degree field of view to accurately identify obstacles
  • Travels at full speed in both forward and backward directions
  • Ideal for both greenfield (new) and brownfield (existing) facilities
  • Accommodates various applications with payload deck configurations (AV toppers)
  • Safe operability with other vehicles and employees through CAT 3 safety system

Specifications

  • Weight Capacity: 200 kg (440 lbs.)
  • Maximum Travel Speed: 1.8 m/s
  • Guidance Method: Natural features navigation via LIDAR
  • Steering Method: Independent drive suspension system with true ZTR (zero turn radius)
  • Power Source: Lithium-ion battery, automatic charging

Bastian Solutions Autonomous & Automated Vehicles

Cb18-automated-forklift-agv-agf-rendering-front

Along with all the brands we integrate, we also design, engineer and manufacture best-in-class automated & autonomous vehicles to help our industry leading customers exceed their system’s throughput goals while reducing operational costs.

Designed and engineered with current manufacturing and warehouse applications in mind, the Bastian Solutions’ AV product line introduces a dependable and flexible alternative to conventional material payload transport methods.


Learn more about Bastian Solutions' Autonomous & Automated Vehicles  >



Learn More

20240726-ML2-spec-sheet-8-thumbnail-card

ML2 Product Overview

M10 Tug AGV

Automated & Autonomous Vehicle Systems
